L. Garth Huxtable Tool Design Gallery

A small subset of Huxtable's tool work is shown here. Many of the images are courtesy of Ada Louise Huxtable or the L. Garth Huxtable Collection at the American Heritage Center at the University of Wyoming, Laramie (now at the Getty Research Institute). Since the images on this page are thumbnails, credit lines appear on the full-size illustrations. Not all of these tools were produced, but they give a good idea of the range of Huxtable's creative abilities.

no. 1814 drill study
No. 1814 drill study
block plane study, 1948
Block plane study, 1948
no. 1434 chisel set
No. 1434 chisel set

Craftsman drill rendering
Craftsman drill rendering
Dunlop & Craftsman attachments
Dunlap & Craftsman drill attachments
hand drill study
Hand drill study

smoothing plane study
Smoothing plane study
micrometer study
Micrometer study
unproduced Plane-R-File
An unproduced Plane-R-File

no. 333 utility knife
No. 333 utility knife
rotatable blade keyhole saw
Rotatable blade keyhole saw
no. 237 keyhole saw
No. 237 keyhole saw

jack plane study
Jack plane study
no. 1414 tubular hack saw frame
No. 1414 tubular hack saw frame
Craftsman glass cutter study
Craftsman glass cutter study

torpedo level study
Torpedo level study
Huxtable's drafting table
Huxtable's drafting table
belt sander renderings
Belt sander renderings
